1. The main frame uses 75*130*3.0mm oval tubing, the functional area uses 58*101*3.0mm elliptical tubing, the force arm in the functional area is made from Φ60mm round tubing, and the connecting tubes are 70*140*3.0mm rectangular tubing.
2. The overall structure is ergonomically designed to ensure scientifically correct motion angles and trajectories. The centerless ground alloy steel guide rods ensure smooth operation without obstructions, and the parabolic curve design of the main frame adds a stylish and elegant appearance.
3. The pulleys are made from POM material, designed with an arc-shaped curve that aligns with muscle movement biomechanics.
4. Quick and convenient adjustments for left and right rotation settings, with no dead zones, ensuring effective muscle engagement and results.
5. The front and rear shields are made from transparent ABS with a smoked finish and a textured surface that resists scratches. The aluminum alloy edging and specialized upper and lower decorative pieces add a luxurious touch.
6. The seat and backrest cushions are made from integrated MC foam with a PU leather cover, featuring a curved headrest and an integrated ABS side shield to prevent lateral deviation.
7. The foot pedals are die-cast from aluminum alloy, offering durability and an attractive appearance. The pedal height is adjustable, with a dual alloy guide rail and assisted structure design for safety and convenience.
8. The training range is adjustable with a pull-rod adjustment mechanism, providing quick and easy customization for safety and convenience.
9. Equipped with forearm support pads and handles, ensuring comfortable and effective training.
10. The handles are fitted with anodized aluminum alloy end caps, combining durability and a refined appearance.
11. The 7*19 coated steel cable can withstand a tensile force of 1000 kg.
12. The aluminum alloy handles and 304 stainless steel weight selection pins, equipped with magnetic rings, offer a combination of aesthetics, safety, and durability.
