1. The main frame uses 75*130*3.0mm oval tubing, the functional area uses 58*101*3.0mm elliptical tubing, the force arm in the functional area is made from Φ60mm round tubing, and the connecting tubes are 70*140*3.0mm rectangular tubing.
2. The overall structure is ergonomically designed to ensure scientifically correct motion angles and trajectories. The centerless ground alloy steel guide rods ensure smooth operation with no interruptions, and the parabolic curve design of the main frame offers a stylish and elegant appearance.
3. Dual-position handles follow a parabolic motion path, featuring a dual-axis, dual-track split-point design, allowing the force arms to move independently and ensuring balanced strength between the left and right arms.
4. The front and rear shields are made from transparent ABS with a smoked finish and a textured surface that resists scratches. The aluminum alloy edging and specialized upper and lower decorative pieces add a luxurious touch.
5. The seat and backrest cushions are made from integrated MC foam with a PU leather cover, equipped with an integrated ABS side shield to prevent lateral deviation. The seat height is adjustable with an auxiliary gas spring for added safety and convenience.
6. Stainless steel universal ball joints effectively protect the wrists during exercise, enhancing safety.
7. The force arms feature an internal stop mechanism at the starting position, and the chest pad is adjustable forward and backward, offering a wide range of motion suitable for eccentric training.
8. The handles are equipped with aluminum alloy end caps, anodized for enhanced durability and a refined look.
9. The 7*19 coated steel cable can withstand a tensile force of 1000 kg.
10. The aluminum alloy handles and 304 stainless steel weight selection pins with magnetic rings offer a combination of aesthetics, safety, and durability.
